Key Points
- Supports PV-Storage-Charging Scenarios, Microgrid and Backup Power
- Rack-mounted Modular Design, Flexible for Configuration and Expansion
- High Conversion Efficiency and Energy Utilization Rate
- Supports Operation Monitoring, Energy Management and Remote Device Upgrading
Specifications
DC Parameters
| Max. Power (kW) | 330 |
|---|---|
| DC Voltage Operating Range (V) | 600...950 |
| Max. DC Current (A) | 660 |
AC Parameters (On-grid)
| Rated Power (kW) | 300 |
|---|---|
| Max. Output Power (kW) | 330 |
| Rated Output Current (A) | 432 |
| Rated Frequency AC (Hz) | 50(±5) |
| Rated Voltage AC (V) | 400V |
| AC Wiring Method | 3W+N+PE |
| Power Factor | -1...+1 |
AC Parameters (Off-grid)
| Rated Power (kW) | 300 |
|---|---|
| Rated Voltage (V) | 400 |
| Switch Time (ms) | < 20 |
General Data
| Protection Level | IP55 |
|---|---|
| Inverter Topology | Transformer isolation |
| Operating Humidity Range | 0...95% (non-condensing) |
| Noise (dB) | < 75 |
| Operating Temperature Range | -20°C...+55°C (derating @ >45°C) |
| Cooling Method | Air cooling |
| Altitude (m) | 2000 |
| Communication Protocols | RS485/CAN/Ethernet |
| Dimensions (W*D*H) (mm) | 1750*1350*2300 |
| Weight (t) | ~2.9 |
| *The dimensions and weights in the table are for outdoor models with transformers, and the weight may be adjusted according to changes in the model and module. | |
