Key Points
- RFID Activation, Customizable Enclosure Choice
- Multi Communications, App Charging Scheduling
- Dynamic Load Balancing, OCPP 1.6 Protocol
- 0 Emission PV Charging with Adjustable Current
- 30mA Type A + 6mA DC, Relay-Sticking Protection
- Convenient Back Plate for Easy Cable Access
Specifications
Input
| Power Supply | 3P+N+PE |
|---|---|
| Rated Voltage | 400 V |
| Rated Current | 32 A |
| Frequency | 50 / 60 Hz |
| Power Measurement Accuracy | 2% |
Output
| Output Voltage | 400 V |
|---|---|
| Max. Current | 32 A |
| Output Power | 22 kW |
Basic Attributes
| Charge Connector | Type 2 Cable |
|---|---|
| Enclosure | PC943 |
| Product Dimension (W*D*H) | 226*164*374 mm |
| Cable Length | 7 m |
| Installation | Wall-mount / Pole-mount |
Interface
| LED Indicator | Green / Yellow / Red |
|---|---|
| RFID Reader | MIFARE ISO / IEC 14443A |
| Start Mode | Plug to Charge / RFID card / App |
Communication
| Wi-Fi | Standard |
|---|---|
| Bluetooth | Standard |
| 3G/4G | Standard |
| Ethernet | Standard |
| Protocol | OCPP 1.6 Json |
Secure and Safety
| RCD | 30mA Type A + 6mA DC |
|---|---|
| Ingress Protection | IP65 |
| Impact Protection | IK10 |
| Electrical Protection | Over current protection, Residual current protection, Surge protection, Over / Under voltage protection, Over / Under frequency protection, Over temperature protection |
| Certification | CE / CB / RoHS / Reach / EN 303645, RCM |
| Certification Standard | IEC 61851-1:2017, EN IEC 61851-1:2019, EN IEC 61851-21-2:2021, EN IEC 61000-6-1:2019, EN IEC 61000-6-3:2007+A1, EN 300 328 V2.2.2:2019, EN 300 330 V2.1.1:2017, EN 301 489-1 V2.2.3:2019, EN 301 489-3 V2.1.1:2019, EN 301 489-17 V3.2.0:2017, EN 62311:2020, BS 7671:2018+A2:2022 |
| For all standards refer to the certificates category on the WHES website. | |
Environment
| Work Temperature | -30°C...+50°C |
|---|---|
| Work Humidity | 5%...95% |
| Work Altitude | ≤ 2000 m |
Package
| External Package | Carton |
|---|
