Key Points
- Optional Cable/Socket, Wall-Mount and Pole-Mount Installation
- Automatic Switching Between Single-Phase and Three-Phase
- Plug and Play, Easy Installation
- IP65 for Indoor or Outdoor Application, Anti-Welding Protection
- Load Balancing System Control
- Remote Control, Compatible with PV & BESS
Specifications
Input
| Power Supply | 3P+N+PE |
|---|---|
| Rated Voltage | 400 V |
| Rated Current | 16 A |
| Frequency | 50/60 Hz |
Output
| Output Voltage | 400 V |
|---|---|
| Max. Current | 16 A |
| Output Power | 11 kW |
User Interface
| Charge Connector | Type 2 cable (Type 2 socket optional) |
|---|---|
| Cable Length | 4 m |
| Housing Material | Plastic PC940 |
| LED Indicator | Green/Yellow/Red |
| RFID Reader | Mifare ISO/IEC 14443 A |
| Start Mode | Plug&Play/RFID card/App |
Communication
| Wi-Fi | Wi-Fi (2.4 GHz) |
|---|---|
| Bluetooth | Optional |
| 3G/4G | Optional |
| Ethernet | Optional |
| Protocol | OCPP 1.6J |
Secure and Safety
| RCD | 30mA Type A + 6mA DC |
|---|---|
| Ingress Protection | IP65 |
| Impact Protection | IK10 |
| Electrical Protection | Over current protection, Residual current protection, Surge protection, Over/under voltage protection, Over/under frequency protection, Over temperature protection |
| Standard | CE, EN/IEC 61851-1: 2019, EN/IEC 61000-6-1:2019, EN/IEC 61000-6-2:2019, EN/IEC 61000-6-4:2019 |
| For all standards refer to the certificates category on the WHES website. | |
Environment
| Installation | Wall-mount/Pole-mount |
|---|---|
| Work Temperature | -30°C...+50°C |
| Work Humidity | 5%...95% |
| Work Altitude | < 2000 m |
Dimension
| Product Dimension (W*D*H) | 201*100*344 mm Cable Series 201*135*344 mm Socket Series |
|---|
