NEW
Key Points
- Dual 3K, Dual-lens Double Vision for Complete Coverage
- Dual Channel Smart Detection: AI Human & Vehicle Detection
- Linkage Tracking & Tap and View (2.8mm+6mm version)
- Smart Dual Light, Sound and Light Alarm to Deter Intruders
- Auto Tracking, Wi-Fi 6, Bluetooth Pairing
- IP66 Protection, Micro SD Card Local Storage
Specifications
Camera (2.8 mm+6 mm)
| Image Sensor | 1/3" CMOS |
|---|---|
| Max. Resolution | 2880 (H) × 1620 (V) |
| Illumination Distance | Fixed Lens: 30 m (98.43 ft) (IR); 20 m (65.62 ft) (Warm light) PT Lens: 50 m (164.04 ft) (IR); 40 m (131.23 ft) (Warm light) |
| Illuminator Number | 4 (IR LED); 4 (Warm light) |
| Angle Adjustment | Pan: 0° to 352°; Tilt: 0° to 90° |
| Lens Type | Fixed-focal |
| Focal Length | Fixed Lens: 2.8 mm PT Lens: 6 mm |
| Max. Aperture | F1.6 |
| Field of View | Fixed Lens: H: 95°; V: 53°; D: 110° PT Lens: H: 49°; V: 26°; D: 57° |
Camera (3.6 mm+3.6 mm)
| Image Sensor | 1/3" CMOS |
|---|---|
| Max. Resolution | 2880 (H) × 1620 (V) |
| Illumination Distance | Fixed Lens: 30 m (98.43 ft) (IR); 20 m (65.62 ft) (Warm light) PT Lens: 50 m (164.04 ft) (IR); 40 m (131.23 ft) (Warm light) |
| Illuminator Number | 4 (IR LED); 4 (Warm light) |
| Angle Adjustment | Pan: 0° to 352°; Tilt: 0° to 90° |
| Lens Type | Fixed-focal |
| Focal Length | 3.6 mm |
| Max. Aperture | F1.6 |
| Field of View | H: 78°; V: 42°; D: 92° |
Intelligence
| Human Detection | Yes |
|---|---|
| Vehicle Detection | Yes |
Audio and Video
| Video Compression | H.265 |
|---|---|
| Video Frame Rate | Main stream: 2880 × 1620@15 fps Sub stream: 640 × 360@15 fps *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Video Bit Rate | H.265: 768 kbps–4096 kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| WDR | DWDR |
| Motion Detection | Yes |
| Image Rotation | 0°/180° |
| Built-in MIC | Yes, built-in Mic |
| Built-in Speaker | Yes, built-in speaker |
| Audio Compression | G.711a; AAC-LC |
Network
| Network Port | RJ-45 (10/100 Base-T) |
|---|---|
| Wi-Fi | IEEE 802.11b/g/n/ax 2.412–2.472 GHz, 2.4 G |
| Wi-Fi Pairing | Bluetooth pairing |
| Storage | Micro SD card (support max. 256 GB) |
| Management Software | DMSS |
| Mobile Client | Android; iOS |
General
| Certifications | CE |
|---|---|
| Power Supply | 12 VDC |
| Power Consumption | Basic: 2.6 W Max.: 10.6 W (pulling stream + IR + siren and light active deterrence) |
| Operating Temperature | –30 °C to +50 °C (–22 °F to +122 °F) |
| Operating Humidity | ≤95% (RH), non-condensing |
| Protection | IP66 |
| Anti-corrosion Level | Basic Protection |
| Casing Material | Plastic |
| Product Dimensions | 159.4 mm × 119.1 mm × 210 mm (6.28" × 4.69" × 8.27") (L × W × H) |
| Net Weight | 585 g (1.29 lb) |
| *The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection. | |
