Key Points
- 8MP Ultra HD with 1/1.8-inch Sensor
- Super-sensitive Imaging Technology
- Vehicle Analytics and Classfication
- IP68 Waterproof and IK10 Vandal Proof
- Dual Light Technology
- Support 4G (GSM/WCDMA/LTE)
Specifications
Camera
| Image Sensor | 1/1.8" CMOS |
|---|---|
| Pixel | 8MP |
| Shutter Mode | Single shutter |
| Electronic Shutter Speed | Auto/Manual 1/50 s–1/100,000 s |
| Noise Reduction | 3D NR |
| S/N Ratio | > 56 dB |
| WDR | 140 dB |
| Min. Illumination | 0.0001 lux |
Illuminator
| Illuminator Number | 3 illuminators (850 nm LED illuminator or 3500 K LED illuminator) |
|---|---|
| Illuminator Brightness Adjustment | brightness adjustable |
| Illumination Distance | 23 m–30 m (75.46 ft–98.43 ft) (adjustable brightness) |
| Lane Coverage | 1–3 lanes |
Lens
| Lens | Included |
|---|---|
| Lens Type | Motorized vari-focal |
| Focal Length | 8 mm–32 mm |
| Max. Aperture | Max. F1.6 |
| Field of View | H: 42°–15°; V: 22.8°–8.4°; D: 48.7°–17.1° |
| Exposure Mode | Auto; Manual (Select from shutter values or customize shutter range) |
Function
| Trigger Mode | Video trigger/Radar trigger |
|---|---|
| OSD Overlay | Time, address, device SN, lane No., plate number, plate color, vehicle logo, vehicle type, vehicle color, vehicle size, vehicle speed, country/region, event (violation name), and motorcycle attributes (type, number of people, and helmet) |
| Alarm Event | Storage full; storage error; external alarm; no storage card; license plate blocklist; illegal access; network disconnection; IP conflict; intrusion; unlicensed vehicle |
| Automatic Network Replenishment (ANR) | Platform and FTP (TF card is required) |
| Auto Registration | Yes |
Intelligence
| Target Detection | Motor vehicle; motorcycle |
|---|---|
| ANPR | Adopts deep-learning algorithms to recognize license plate numbers and letters |
| Vehicle Type Recognition | Vehicle head: SUV, Large bus, sedan, light truck, pickup, heavy truck, medium truck, van, medium bus, MPV Vehicle tail: SUV, large bus, sedan, light truck, pickup, heavy truck, medium truck, van |
| Vehicle Color Recognition | White, pink, black, red, yellow, gray, blue, green, dark orange, purple, brown, and silver gray |
| Vehicle Brand/Logo Recognition | Acura; Alfaromeo; Ashokleyland; Astonmartin; Audi; Baic; Bently; Benz; BMW; Buick; BYD; Cadillac; Chery; Chevrolet; Chrysler; Citroen; Dacia; Daihatsu; Datsun; Dodge; DS; Ferrari; Fiat; Force; Ford; Foton; Geely; GMC; Greatwall; Hino; Honda; Hyundai; Infiniti; Isuzu; Iveco; Jac; Jaguar; Jeep; Kia; Kinglong; Land; Lexus; Lifan; Lincoln; Mahindra; MAN; Maserati; Mazda; Mercury; MG; Mini; Mitsubishi; Nissan; Opel; Peugeot; Porsche; Renault; Rollsroyce; Saab; Scania; Seat; Skoda; Smart; Subaru; Suzuki; Tata; Tesla; Toyota; UD; Volkswagen; Volvo |
| Motor Vehicle Violation Capture | Speeding; driving slow; wrong-way driving; illegal lane change |
| Motorcycle Violation Capture | Captures traffic violations including carrying passenger, not wearing helmet, and wrong-way driving |
| Traffic Flow Detection | Supports data classification and generating statistics on lanes, vehicle type, speed, and the date. The results can be exported to the CSV file format. |
| Traffic Event | Motor vehicle illegal stopping on the roadway; traffic congestion |
| Capture Speed | Up to 180 km/h |
Video
| Video Compression | H.265;H.264M;H.264H;MJPEG |
|---|---|
| Video Resolution | 8MP (3840× 2160); 1080p (1920 × 1080); 720p (1280 × 720); |
| Video Frame Rate | 50 Hz: Maximum 25 fps; default main stream (3840 × 2160@25 fps), sub stream (1280 × 720@25 fps) 60 Hz: Maximum 30 fps; default main stream (3840 × 2160@30 fps), sub stream (1280 × 720@30 fps) |
| Video Bit Rate | H.264: 32 kbps–32768 kbps H.265: 32 kbps–32768 kbps MJPEG: 512 kbps–32768 kbps |
| Bit Rate Control | VBR;CBR |
| White Balance | Auto;Manual;Outdoor;Natural;Street Lamp;Partial white balance |
| Edge Enhancement | Yes |
| HLC | Yes |
| BLC | Yes |
| Bad Pixel Correction | Yes |
| Gain Range | 0-100 |
| Composite Image | Supports combining up to 3 source images, and 1 closeup image into a composite image |
|---|---|
| Image Resolution | 3840 (H) × 2160 (V) (OSD black background is not calculated in the pixels) |
| Image Encoding Format | JPEG |
| Image Tampering Prevention | Verifies watermarks in videos and images |
Network
| Network Port | 1 × RJ-45 Ethernet port |
|---|---|
| SDK and API | Yes |
| Security Mode | Authorized username and password, MAC address binding, HTTPS encryption, and network access control |
| Network Protocol | HTTP;HTTPS;IPv4;RTSP;UDP;NTP;DHCP;DNS;IPv6;802.1x;FTP;UPnP;ARP;RTCP;RTP;TCP;IP |
| Interoperability | ONVIF (Profile S & Profile G & Profile T & Profile M) |
| Browser | Microsoft Edge Chrome: Chrome 41 and earlier Firefox: Firefox 49 and earlier For Win 10 users, run the browser as administrator |
| Timing | NTP |
| 4G Type | GSM/WCDMA/LTE |
| 4G Frequency Range | NL668-EAU: LTE FDD: Band 1/3/7/8/20/28 LTE TDD: Band 38/40 WCDMA: Band 1/8 GSM: 900/1800 MHz NL668-LA: LTE FDD: Band 1/2/3/4/5/7/8/28/66 LTE TDD: Band 38/40 WCDMA: Band 1/2/3/4/5/8 GSM: 850/900/1800 MHz |
| 4G Power Transmission | NL668-EAU: LTE: Power class3: 23 dBm±2 dB WCDMA: Power class3: 24 dBm+1/-3 dB GSM: Power class0: 30 dBm±2 dB (GSM1800); Power class5: 33 dBm±2 dB (GSM900) NL668-LA: LTE: Power class3: 23 dBm± 2dB WCDMA: Power class3: 24 dBm+1/-3 dB GSM: Power class0: 30 dBm±2dB（GSM1800); Power class5: 33 dBm±2dB (GSM850/900) |
Port
| Storage | 1, supports maximum 1 TB TF card local storage |
|---|---|
| RS-485 | 1 |
| RS-232 | 1 |
| Alarm Input | 1 channel |
| Alarm Output | 2 channels |
General
| Power Supply | 12 VDC;PoE |
|---|---|
| Power Consumption | With light turned off < 8.5 W With IR light turned on < 12.5 W With warm light turned on < 17.5 W |
| Operating Temperature | –30 °C to +65 °C (–22 °F to +149 °F) |
| Storage Temperature | –30 °C to +65 °C (–22 °F to +149 °F) |
| Operating Humidity | 10%–90% (RH), non-condensing |
| Storage Humidity | 0%–90% (RH), non-condensing |
| Protection | IK10;IP68 |
| Anti-corrosion Level | Basic Protection *The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection. |
| Certifications | CE EMC:EN 61000-3-3;EN IEC 61000-3-2;EN 301 489-1;EN 301 489-51;EN 301 489-52;EN 301 511;EN 301 908-1;EN 301 908-2;EN 301 908-13;EN 305 550-2;EN IEC 62311 CE LVD:EN62368-1 CE RED:EN 61000-3-3;EN IEC 61000-3-2;EN 301 489-1;EN 301 489-51;EN 301 489-52;EN 301 511;EN 301 908-1;EN 301 908-2;EN 301 908-13;EN 305 550-2;EN IEC 62311 IK10:IEC60068-2-75:2014 IP68：IEC60529:2013 |
| Product Dimensions | 350 mm × 109 mm × 150 mm (13.78" × 4.29" × 5.91") (L × W × H) |
| Packaging Dimensions | 400 mm × 197 mm × 171 mm (15.75" × 7.76" × 6.73") (L × W × H) |
| Net Weight | 1.744 kg (3.84 lb) |
| Gross Weight | 2.384 kg (5.26 lb) |
| Installation | Installs with universal mounting brackets, or as a side-mount with mounting brackets |
