Key Points
- 60 GHz FMCW Millimeter-Wave Radar, up to 4 GHz Active Bandwidth
- Accurately Distinguishes Pedestrians, Vehicles and Other Objects
- Compatible with Advertising, Fence, Straight-Arm and Folding-Arm Barriers
- Digital Beamforming (DBF) with Narrow-Beam Logic Reduces False Alarms
- Online Commissioning and Firmware Update via App and Serial Port
- IP67 Protection, Compact and Cost-Effective RFSoC Design
Specifications
Basic
| Radar Modulation Type | FMCW |
|---|---|
| Radar Frequency Range | 60 GHz–64 GHz |
| Radar Power Transmission | 11 dBm |
| Bluetooth Standard | BLE5.0 |
| Bluetooth Frequency Range | 2.402 GHz–2.480 GHz |
| Bluetooth Power Transmission | ≤8 dBm |
| Beamwidth | Vertical 20° (-6° to +14°), horizontal 120° (±60°) |
| Response Time | 100 ms |
| Detection Region | 1.5 m (4.92 ft) (default, adjustable) |
| Anti-smashing Region | 0 m–6 m (0 ft–19.69 ft) |
Function
| Detection Target | person/vehicle |
|---|---|
| Online Commissioning | Yes (debugging by app and serial port) |
| Update | Yes (online update through app and serial port) |
| Snapshot Mode | Yes |
Port
| RS-485 | 1 |
|---|---|
| I/O | 1 channel |
General
| Operating Voltage | 9–24 VDC |
|---|---|
| Operating Current | 50 mA |
| Power Consumption | <0.5 W (average power consumption) |
| Operating Temperature | –40 °C to +85 °C (–40 °F to +185 °F) |
| Storage Temperature | –10 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity | 0%–90% (RH), non-condensing |
| Storage Humidity | 0%–90% (RH), non-condensing |
| Protection | IP67 |
| Anti-corrosion Level | Basic Protection |
| Product Dimensions | 107.9 mm × 73.6 mm × 33.2 mm (4.25" × 2.9" × 1.31") (L × W × H) |
| Packaging Dimensions | 164 mm × 113 mm × 49 mm (6.46" × 4.45" × 1.93") (L × W × H) |
| Net Weight | 118 g (0.26 lb) |
| Gross Weight | 293 g (0.65 lb) |
| Installation | Side installation |
| *The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection. | |
