NEW
Key Points
- 4MP Clear Images with Sharp Details
- AI Human & Vehicle Detection, AI Chip for Enhanced Accuracy
- Wi-Fi & PoE Integration, Flexible Power Delivery
- Day & Night, Two-way Talk, Bluetooth Pairing
- H.265 Advanced Compression Technology
- Micro SD Card Local Storage
Specifications
Camera
| Image Sensor | 1/3" CMOS |
|---|---|
| Max. Resolution | 2560 (H) × 1440 (V) |
| Illumination Distance | Up to 30 m (98.43 ft) (IR) |
| Illuminator Number | 1 (IR LED) |
| Angle Adjustment | Pan: 0° to 360° Tilt: -10° to 100° |
Lens
| Lens Type | Fixed-focal |
|---|---|
| Focal Length | 2.8 mm; 3.6 mm |
| Max. Aperture | F2.0 |
| Field of View | 2.8 mm: H: 92°; V: 50°; D: 107° 3.6 mm: H: 75°; V: 41°; D: 88° |
Intelligence
| Human Detection | Yes |
|---|
Audio and Video
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
|---|---|
| Video Frame Rate | Main stream: 2560 × 1440@(1-25/30 fps) Sub stream: 640 × 360@(1-25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Video Bit Rate | H.264: 24 kbps–6144 kbps H.265: 9 kbps–6144 kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| WDR | Yes |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Image Rotation | 0°/180° |
| Built-in MIC | Yes, built-in Mic |
| Built-in Speaker | Yes, built-in speaker |
| Audio Compression | PCM; G.711a; G.711Mu |
Network
| Network Port | RJ-45 (10/100 Base-T) |
|---|---|
| Wi-Fi | IEEE 802.11b/g/n/ax 2.412–2.472 GHz, 2.4 G |
| Wi-Fi Pairing | Bluetooth pairing |
| Storage | Micro SD card (support max. 256 GB) |
| Management Software | Smart PSS Lite; DMSS |
| Mobile Client | iOS; Android |
Function
| Abnormal Sound Alarm | Yes |
|---|
General
| Certifications | CE |
|---|---|
| Power Supply | 12 VDC/PoE |
| Power Consumption | Basic: 2.04 W (12 VDC); 4.7 W (PoE) Max.: 2.89 W (12 VDC); 5.85 W (PoE) |
| Operating Temperature | –10 °C to +45 °C (+14 °F to +113 °F) |
| Operating Humidity | ≤95% (RH), non-condensing |
| Camera Button | Reset button |
| Casing Material | Plastic |
| Product Dimensions | 64 mm × 100 mm × 34 mm (2.52" × 3.94" × 1.34") (L × W × H) |
| Net Weight | 0.11 kg (0.24 lb) |
