NEW
Key Points
- Max. 15 fps @ 4K, Starlight Technology for Low-Light Performance
- 120 dB True WDR, 3D NR
- Smart IR Illumination, 80 m Illumination Distance
- Auto Focus, 2.7 mm–13.5 mm Motorized Vari-focal Lens
- CVI/CVBS/AHD/TVI Switchable
- IP67 Protection, 24 VAC/12 VDC
Specifications
Camera
| Image Sensor | 4K CMOS |
|---|---|
| Max. Resolution | 3840 (H) × 2160 (V) |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/3 s–1/100,000 s NTSC: 1/4 s–1/100,000 s |
| Min. Illumination | 0.001 lux@F1.5 (Color, 30 IRE) 0.0001 lux@F1.5 (B/W, 30 IRE) 0 lux (Illuminator on) |
| S/N Ratio | >65 dB |
| Illumination Distance | 80 m (262.47 ft) |
| Illuminator On/Off Control | Auto |
| Illuminator Number | 4 (IR light) |
| Pan/Tilt/Rotation Range | Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360° |
Lens
| Lens Type | Motorized Vari-focal |
|---|---|
| Auto Focus | Yes |
| Lens Mount | φ14 |
| Focal Length | 2.7 mm–13.5 mm |
| Max. Aperture | F1.5 |
| Field of View | H: 113°–47°; V: 60°–26°; D: 133°–53° |
| Iris Control | Fixed |
| Close Focus Distance | 1.2 m (3.94 ft) |
| DORI Distance | Lens Detect Observe Recognize Identify 2.7 mm 83.4 m (273.62 ft) 33.4 m (109.58 ft) 16.7 m (54.79 ft) 8.3 m (27.23 ft) 13.5 mm 189.6 m (622.05 ft) 75.8 m (248.69 ft) 37.9 m (124.34 ft) 19.0 m (62.34 ft) |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. | |
Video
| Video Frame Rate | CVI: PAL: 4K@15 fps; 5M@25 fps; 4M@25 fps NTSC: 4K@15 fps; 5M@25 fps; 4M@30 fps AHD: PAL: 4K@15 fps; NTSC: 4K@15 fps TVI: PAL: 4K@15 fps; NTSC: 4K@15 fps CVBS: PAL: 960H; NTSC: 960H |
|---|---|
| Resolution | 4K (3840 × 2160); 5M (2880 × 1620); 4M (2560 × 1440); 960H (960 × 576/960 × 480) |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC | BLC; HLC; WDR; HLC-Pro |
| WDR | 120 dB |
| White Balance | Auto; Area white balance |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D NR |
| Illumination Mode | Smart IR |
| Defog | Electronic defog |
| Digital Zoom | 4× |
| Mirror | Yes |
| Privacy Masking | Off/On (8 areas, rectangle) |
Certification
| Certifications | CE-LVD: EN 62368-1; CE-EMC: EN 55032; EN 55035; FCC: 47 CFR FCC Part 15, Subpart B; UL: UL62368-1 + CAN/CSA C22.2 No. 62368-1-14 |
|---|
Port
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP switch) |
|---|---|
| Audio Input | One channel built-in MIC |
Power
| Power Supply | 12 VDC ± 10%; 24 VAC ± 25% |
|---|---|
| Power Consumption | Max. 13.9 W (12 VDC, IR on) |
Environment
| Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
|---|---|
| Operating Humidity | <95% (RH), non-condensing |
| Storage Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Storage Humidity | <95% (RH), non-condensing |
| Protection | IP67 |
Structure
| Casing Material | Metal |
|---|---|
| Product Dimensions | 244.1 mm × 90.4 mm × 90.4 mm (9.61" × 3.56" × 3.56") |
| Net Weight | 0.82 kg (1.81 lb) |
| Gross Weight | 1.13 kg (2.49 lb) |
| Installation | Wall mount; ceiling mount; vertical pole mount |
